Deicing fluid (type 1) 2000 litres insulated tank
Anti-icing fluid (type 3-4) 750 litres insulated tank
Access doors and storage
Access door on both sides for easy maintenance.
Main components such as pumps, engine, regulators, sensors,
flow switch, adjustment valves, filters and hydraulics
are easily accessible through doors.
Storage compartment in front of unit.
Working height of 34 feet
12 VDC hydraulic pump
Ladder rotates 360 degrees
Heating system (type 1)
The heating system is equipped with one Beckett burners and has two heating modes.
Standby mode designed by Cam-Concept preheats fluid at 120 F without degradation of the de-icing fluid.
Normal mode heats product up to 180°F when a de-icing operation is confirmed.
Deicing system (type 1)
Centrifuge 30 gallons/minute pump at 100 psi. Task Force Tips nozzle.
50 feet hose and nozzle with automatic reel for overwing and underwing use.
Anti-icing system (type 3-4)
Hardy 18 gallons/minute diaphragm pump at 140 psi.
Task Force Tips nozzle.
Auto pumping system using the type 1 and type 3-4 internal pumps.
Tanks can also be filled using the top mounted filler caps.
120/240 15 kW gas generator. Diesel engine optional.
Powerful LED lights on bucket and on control panel.
Two strobe lights.
Fire extinguishers near bottom of ladder.
One-year parts and labor.
